Heater Case with Blower for 2012 Mercedes-Benz S400
No.
Part # / Description / Price
Price
20
Sealing Ring
Mercedes-Benz
Mercedes-Benz Description: PIPE TO HEAT EXCHANGER
Strength / hardness class: EPDM
Inside diameter: 17,12mm
Outside diameter: 22,36mm
Material thickness: 2,62mm. Front.
Strength / hardness class: EPDM
Inside diameter: 17,12mm
Outside diameter: 22,36mm
Material thickness: 2,62mm. Front.
$8.40
$8.40
25
$33.35
40
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
50
$10.32
55
Tension Spring Mercedes-Benz
Mercedes-Benz Description: Air conditioner case. Air baffle. Upper part to lower part. Blower case. Air conditioner housing mount TO A463 830 06 62,209 830 01 62. Air distributor. Heater housing. At heater case.
$7.65
$7.65
60
70
$84.10
90
Stepper Motor Mercedes-Benz
Mercedes-Benz Description: Servomotor. Circulating air flap. Air distributor. Fresh air/circulating air. Ventilation flap. Heater/air conditioning.
$130.50
$130.50
100
Temperature Sensor Mercedes-Benz
Mercedes-Benz Description: Sprinter van. To evaporator. Left front in air conditioner housing. Temperature sensor. Heater/air conditioning TO A463 830 06 62,209 830 01 62. Metris. Rear. For Primary HVAC.
$171.50
$171.50
110
Dampening Mercedes-Benz
Mercedes-Benz Description: Heater case to fire wall. Fire wall decoupling. To evaporator housing. Heater box to firewall. Heater box/air conditioner box.
$15.38
$15.38
120
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: CONTROL UNIT MUST BE FLASHED WITH CORRESPONDING FLASHWARE
PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Kla. Air conditioner.
$524.05
$524.05
170
Seal Mercedes-Benz
Mercedes-Benz Description: Air conditioner case. Blower housing on firewall. Fresh-air intake.
$31.90
$31.90
200
210
901
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
$15.75
$15.75
904
Plug Mercedes-Benz
Mercedes-Benz Description: Blower regulator n29. 4-pin mcp2.8/6.3
model 1: mcp
model 2: 2.8 / 6.3
slots: 4. Blower regulator n 29. 4-pin mcp2.8/6.3
model 1: mcp
model 2: 2.8 / 6.3
slots: 4.
model 1: mcp
model 2: 2.8 / 6.3
slots: 4. Blower regulator n 29. 4-pin mcp2.8/6.3
model 1: mcp
model 2: 2.8 / 6.3
slots: 4.
$8.80
$8.80
905
Receptacle Mercedes-Benz
Mercedes-Benz Description: Silver-plated. 4.0 MM2 MCP6.3Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 6.3. BLOWER REGULATOR N29. 4.0 MM2 MCP6.3Leitungsquerschnitt Min/Max: 4,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 6.3. CON ...
$9.20
$9.20
905
Contact Socket Mercedes-Benz
Mercedes-Benz Description: STOP LIGHT SWITCH S9/1. 0.5-1.0 MM2 MCP2.8Leitungsquerschnitt Min/Max: 0,5-1,0mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. BLOWER REGULATOR N29. 0.5-1.0 MM2 MCP2.8Leitungsquerschn ...
$12.75
$12.75
906
Plug Housing, Rectangular Mercedes-Benz
Mercedes-Benz Description: Servomotor. 4-pin mqsmodel 1: mqsslots: 4. Actuator, air distributor, left m16/33. 4-pin mqsmodel 1: mqsslots: 4. Actuator motor, air flap, center nozzle, left and right m16/23, m16/24. 4-pin mqsmodel 1: mqsslots: 4. Actuator motor for air flap, rear cente ...
$8.50
$8.50
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
