Door Wiring Harness and Door Control Module for 2012 Mercedes-Benz S400
No.
Part # / Description / Price
Price
10
10
Electric Line
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Window lifter at driver door, left.
30
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left front door control unit.
$371.30
$371.30
30
Control Unit, Door Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left front door control unit.
30
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Right front door control unit.
$401.85
$401.85
30
Control Unit, Door Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Right front door control unit.
30
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
Description: Left front door control unit.
$421.83
$421.83
30
Control Unit, Door Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Right front door control unit.
30
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Right front door control unit.
30
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left front door control unit.
30
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Right front door control unit.
30
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Right front door control unit.
$364.25
$364.25
30
Control Unit, Door Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left front door control unit.
30
Control Unit, Door Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left front door control unit.
40
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left and right rear doors.
40
Control Unit 1 Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Rear door, left.
$321.95
$321.95
40
Control Unit, Door Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Rear door, left.
40
Control Unit, Door Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left and right rear door.
40
Control Unit Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Rear door, left.
40
Control Unit, Door Mercedes-Benz
Mercedes-Benz Notes: PART MUST BE CHECKED FOR CURRENT FLASHWARE AFTER INSTALLAT ION
Description: Left and right rear doors.
50
Hexalobular Screw Mercedes-Benz
Mercedes-Benz Description: At door handle m 6x12. M6X12-8.8-MK
Diameter: 6mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Door handle to door.
Diameter: 6mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Door handle to door.
$6.18
$6.18
60
Electric Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Window lifer at rear door, left.
60
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Rear door left, for keyless go.
60
70
$8.40
70
Screw Mercedes-Benz
Mercedes-Benz Description: Fastening electric motor. M5X30
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Engine fixing. Cable tray to apparatus case. Turn signal lamp to fender. Door separation point, rear.
Diameter: 5mm
Strength / hardness class: 8.8
Thread code letter: M
Thread pitch: 1mm. Engine fixing. Cable tray to apparatus case. Turn signal lamp to fender. Door separation point, rear.
70
$4.73
900
Socket-Outlet Mercedes-Benz
Mercedes-Benz Description: Keyless-go control unit, plug 4. 10-pin mqs. N69/2. 10-pin mqs. Front loudspeaker. 10-pin mqs. Folding top actuation switch s84. 10-pin mqs. N69/1. Left front door control unit. Connector: 5. 10-pin mqs. Control unit keyless go blue n69/5. 10-pin mqs. Connector cockpit/frame floor system x18. 10-pin mqs.
$28.28
$28.28
900
Plug Mercedes-Benz
Mercedes-Benz Description: Driver dynamic seat control unit n32/19*1. 7-pin mqs, mcp2.8model 1: mqs/mcpmodel 2: 2.8slots: 7release tool: w220 589 01 99 60 / w000 589 13 99 30. Front passenger dynamic seat control unit n32/22*1. 7-pin mqs, mcp2.8model 1: mqs/mcpmodel 2: 2.8slots: 7re ...
900
Housing Mercedes-Benz
Mercedes-Benz Description: Dynamic seat pump A77. 5-PIN MQS, MCP2.8Model 1: MQS/MCPModel 2: 2.8Slots: 5Release tool: W220 589 01 99 60 / W000 589 13 99 30. Sam/srb control module rear neutral n10/2,. 5-pin mqs, mcp2.8model 1: mqs/mcpmodel 2: 2.8slots: 5release tool: w220 589 01 99 6 ...
901
Contact Socket Mercedes-Benz
Mercedes-Benz Description: BUS NODE (ROOF) N70. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: MCPModel 2: 2.8Release tool: W000 589 13 99 30Crimp tool: W220 589 01 99 05. LEFT TAIL LAMP E3. 1.5-2.5 MM2 MCP2.8Leitungsquerschnitt Mi ...
$15.38
$15.38
901
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
$15.75
$15.75
902
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Door control unit, left and right rear door n69/3, n69/4. 6-pin
model 1: mqs / mcp
model 2: 2.8
slots: 6.
model 1: mqs / mcp
model 2: 2.8
slots: 6.
$9.20
$9.20
906
Plug Mercedes-Benz
Mercedes-Benz Description: Front door connector to frame floor system x35/1 ,x35/2. 2-pin mqsmodel 1: mqsslots: 2. Keyless-go antenna connector x1/51. 2-pin mqsmodel 1: mqsslots: 2. Separation point rear panel door x8/46*3. 2-pin mqsmodel 1: mqsslots: 2. Rear head restraint motor co ...
$10.00
$10.00
907
Crimp Tml Pin Contact Mercedes-Benz
Mercedes-Benz Description: X1/16. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: SnELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. Malfunction indicator lamp aut. Breakdown/information button conn. X 39/48. 0.5-0.75 M ...
$7.01
$7.01
908
Plug Mercedes-Benz
Mercedes-Benz Description: Connector cockpit/frame floor system x18*2. 6-pin slk2.8model 1: slkmodel 2: 2.8slots: 6release tool: w220 589 01 99 62. Separation point trunk lid 6-pin x8/4. 6-pin slk2.8model 1: slkmodel 2: 2.8slots: 6release tool: w220 589 01 99 62. Connector for engin ...
$18.75
$18.75
909
Plug Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 0.5-0.75 MM2 SLK2.8. Front door connector to frame floor system. 0.5-0.75 mm2 slk2.8. Circuit 15r/58d connector x39/29. 0.5-0.75 mm2 slk2.8. Module box separation point x35/15. 0.5-0.75 mm2 slk2.8. Radio remote control separation point for central locking x35/71. 0.5-0.75 mm2 slk2.8. Silver. 0.5-0.75 mm2 slk2.8. 0,5-1,0mm. 0.5-0.75 mm2 slk2.8. To a 220 545 92 28. 0.5-0.75 mm2 slk2.8.
$9.60
$9.60
909
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: Tin-plated. 1.5-2.5 MM2 SLK2.8Leitungsquerschnitt Min/Max: 1,5-2,5mm2Oberflächenschutz PINs: SnELA: -Model 1: SLKModel 2: 2.8Release tool: W220 589 01 99 62Crimp tool: W220 589 01 99 07. FRONT DOOR CONNECTOR TO FRAME FLOOR SYSTEM. 1.5-2.5 MM2 SLK2.8Leitun ...
$9.60
$9.60
912
Plug Mercedes-Benz
Mercedes-Benz Description: Left front seat. 2 pin mqs. Front door connector to frame floor system x35/1 ,x35/2. 2 pin mqs.
$16.90
$16.90
913
Plug Mercedes-Benz
Mercedes-Benz Description: Gold-plated. 0.5-0.75 MM2 MQSLeitungsquerschnitt Min/Max: 0,5-0,75mm2Oberflächenschutz PINs: AuELA: -Model 1: MQSRelease tool: W220 589 01 99 60Crimp tool: W220 589 01 99 85. FRONT DOOR CONNECTOR TO FRAME FLOOR SYSTEM. 0.5-0.75 MM2 MQSLeitungsquerschnitt ...
$13.13
$13.13
914
Plug Mercedes-Benz
Mercedes-Benz Description: Connector, tank (pressure sensor) x25/4. 3-pin mqsmodel 1: mqsslots: 3. Three pin, plug connector sun sensor. 3-pin mqsmodel 1: mqsslots: 3. Front door handle x8/34. 3-pin mqsmodel 1: mqsslots: 3. Rear door handle x8/36. 3-pin mqsmodel 1: mqsslots: 3. Conn ...
$16.90
$16.90
915
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
$17.63
$17.63
930
Plug Mercedes-Benz
Mercedes-Benz Description: Door sill at front left and right, illuminated e17/47, e17/48. 2-pin mqsmodel 1: mqsslots: 2release tool: w220 589 01 99 60. REAR, RIGHT. 2-PIN MQSModel 1: MQSSlots: 2Release tool: W220 589 01 99 60. Connecting point, right speaker x18/13. 2-pin mqsmodel 1 ...
$8.80
$8.80
1 This price excludes a refundable manufacturer's core charge. Add the part to your cart to see the core charge.
