Electronic Stability Program (ESP®) for 2012 Mercedes-Benz S400
No.
Part # / Description / Price
Price
10
Sensor Cluster
Mercedes-Benz
Mercedes-Benz Notes: MAY ONLY BE INSTALLED IN VEHICLES UP TO CODE 807
Description: In center of trunk. Rotation rate sensor 6-pin b24/15. Yaw rate, lateral and longitudinal acceleration sensor. Acceleration pickup.
$561.65
$561.65
10
Sensor Cluster Mercedes-Benz
Mercedes-Benz Description: Acceleration pickup. In center of trunk. Yaw rate, lateral and longitudinal acceleration sensor.
$423.00
$423.00
10
Sensor Cluster Mercedes-Benz
Mercedes-Benz Description: Yaw rate, lateral and longitudinal acceleration sensor. In center of trunk. At tunnel b24/15.
$571.05
$571.05
10
Sensor Cluster Mercedes-Benz
Mercedes-Benz Description: Yaw rate, lateral and longitudinal acceleration sensor b24/15. In center of trunk.
$399.50
$399.50
30
Acceleration Sensor Mercedes-Benz
Mercedes-Benz Description: Lat. Acceleration sensor in wheelhouse, front axle left and right. Front axle vertical accelerator sensor. Acceleration sensor on spring/shock absorber turret. Acceleration, vertical.
$208.25
$208.25
30
Acceleration Sensor Mercedes-Benz
Mercedes-Benz Description: Lat. Rear axle vertical accelerator sensor. Acceleration sensor on spring/shock absorber turret. Front axle vertical accelerator sensor. Acceleration sensor, left and right front.
$131.95
$131.95
45
Hexagon Nut Mercedes-Benz
Mercedes-Benz Description: M6. Bracket to water tank. Mounting parts. Control unit. Bracket mounting. Brake booster assembly to asr bracket. Fuel lines to cowl. Transistorized ignition switchgear to wheelhouse panel. Roller blind to rear panel covering, top.
$8.50
$8.50
50
Acceleration Sensor Mercedes-Benz
Mercedes-Benz Description: Acceleration sensor horizontal, to center tunnel right. Vertical acceleration sensor.
$156.60
$156.60
60
Holder Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Horizontal acceleration sensor. Mounting, sensor.
80
Hexagon Nut With Collar Mercedes-Benz
Mercedes-Benz Description: Oxygen sensor. 5 mm. Bracket mounting. 5 mm. Control module,auxiliary fan. 5 mm.
$9.60
$9.60
100
Turning Angle Sensor Mercedes-Benz
Mercedes-Benz Description: Headlamp range adjustment front. Level sensor to bracket, rear axle. Turning angle sensor. Rear axle level sensor, headlamp range adjustment. Rear axle level sensor for air suspension. Level sensor to front axle wheelhouse. Level sensor in wheelhouse, left front axle. Level sensor for bi-xenon rear axle.
$289.05
$289.05
110
Protective Cap Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Level sensor front axle 6-pin. Control-unit plug-connection. Right turning angle sensor. Left front level sensor.
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Brake assist system and air suspension.
300
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Brake assist system and air suspension.
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Brake assist system and air suspension.
300
Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Brake assist system and air suspension.
320
Distributor Block Mercedes-Benz
Mercedes-Benz Description: Connector, dynamics can bus node x30/28. 5x2/1x3pin. 6-pin. 5x2/1x3pin.
$20.48
$20.48
915
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: 4-PIN MQS
Model 1: MQS
Slots: 4
Release tool: W220 589 01 99 60.
Model 1: MQS
Slots: 4
Release tool: W220 589 01 99 60.
$12.75
$12.75
920
Socket-Outlet Mercedes-Benz
Mercedes-Benz Description: Keyless-go control unit, plug 4. 10-pin mqs. N69/2. 10-pin mqs. Front loudspeaker. 10-pin mqs. Folding top actuation switch s84. 10-pin mqs. N69/1. Left front door control unit. Connector: 5. 10-pin mqs. Control unit keyless go blue n69/5. 10-pin mqs. Connector cockpit/frame floor system x18. 10-pin mqs.
$28.28
$28.28
925
Plug Mercedes-Benz
Mercedes-Benz Description: Can bus node plug-in connector x30/28. 2-pin mqs
model 1: mqs
slots: 2. Potential distributor connector (can) x30/28. 2-pin mqs
model 1: mqs
slots: 2. Can bus node plug-in connector x 30/28. 2-pin mqs
model 1: mqs
slots: 2. Voltage distributor connector (can) left x30/38. 2-pin mqs
model 1: mqs
slots: 2. Connector, potential distributor, drive train sensor can x30/38. 2-pin mqs
model 1: mqs
slots: 2.
model 1: mqs
slots: 2. Potential distributor connector (can) x30/28. 2-pin mqs
model 1: mqs
slots: 2. Can bus node plug-in connector x 30/28. 2-pin mqs
model 1: mqs
slots: 2. Voltage distributor connector (can) left x30/38. 2-pin mqs
model 1: mqs
slots: 2. Connector, potential distributor, drive train sensor can x30/38. 2-pin mqs
model 1: mqs
slots: 2.
930
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Bus node, chassis can/coc x30/31. 2-pin mqsmodel 1: mqsslots: 2. Potential distributor connector (can) x30/30. 2-pin mqsmodel 1: mqsslots: 2. Can bus c, left x30/18. 2-pin mqsmodel 1: mqsslots: 2. Connector voltage distributor 2-pin (can c) x30/18. 2-pin m ...
$8.44
$8.44
935
Contact Carrier Mercedes-Benz
Mercedes-Benz Description: Connector, left rear axle electrical distributor, violet x62/32*4. 4-pin mqs. Connector, rear axle distributor, violet x62/32,x62/33,cod.d. 4-pin mqs. Rear axle separation point x62/8 code d. 4-pin mqs.
$11.20
$11.20
936
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
$15.75
$15.75
940
Holder Mercedes-Benz
Mercedes-Benz Description: Right front axle electrical distributor x62/6. 2-pin (7-pin layout). Plug connection front axle,left and right. 2-pin (7-pin layout). To 036 545 15 28. 2-pin (7-pin layout).
$9.60
$9.60
940
940
Plug Mercedes-Benz
Mercedes-Benz Description: Speed sensor right. Plug connection right front axle distributor x62/6.
$15.75
$15.75
940
Holder Mercedes-Benz
Mercedes-Benz Description: Right front axle electrical distributor x62/6. 7-pin. Plug connection front axle,left and right. 7-pin.
950
Plug Mercedes-Benz
Mercedes-Benz Description: Speed sensor left. Front axle distributor connector left x62/7.
$16.58
$16.58
950
Clutch Housing Mercedes-Benz
Mercedes-Benz Description: Front axle distributor connector left x62/7. Plug connection front axle,left and right.
960
Plug Housing Mercedes-Benz
Mercedes-Benz Description: Airmatic emergency filling connecting point x222. 6-pin mqs
model 1: mqs
slots: 6. Air suspension sep. Point x11/35. 6-pin mqs
model 1: mqs
slots: 6. Front door handle x8/34, x8/35. 6-pin mqs
model 1: mqs
slots: 6. Door separation point. 6-pin mqs
model 1: mqs
slots: 6. From light range regulator to front axle 13-polig. 6-pin mqs
model 1: mqs
slots: 6.
model 1: mqs
slots: 6. Air suspension sep. Point x11/35. 6-pin mqs
model 1: mqs
slots: 6. Front door handle x8/34, x8/35. 6-pin mqs
model 1: mqs
slots: 6. Door separation point. 6-pin mqs
model 1: mqs
slots: 6. From light range regulator to front axle 13-polig. 6-pin mqs
model 1: mqs
slots: 6.
$66.70
$66.70
961
Crimp Tml Pin Contact Mercedes-Benz
