Refrigerant Line Routing for 2016 Mercedes-Benz GLE450 AMG
No.
Part # / Description / Price
Price
200
$171.10
200
$143.55
202
O-Ring
Mercedes-Benz
Mercedes-Benz Description: To evaporator. Line to condenser. Condenser and connecting point 1/2". Condenser to compressor. Pipe line to refrigerant compressor. Piping to refrigerant compressor. Between evaporator and expansion valve.
$16.90
$16.90
202
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: AT CONDENSER. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. PRESSURE LINE TO EXPANSION VALVE. 10.6X2 MMDiameter: 10,6mmInside diameter: 10,6mmOutside diameter: 14,6mmMaterial thickness: 2mm. Refrigerant li ...
205
O-Ring Mercedes-Benz
Mercedes-Benz Description: Sprinter van. Type 1. Refrigerant line to mounting plate. 9.5X2.6
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
Diameter: 9,5mm
Inside diameter: 9,5mm
Outside diameter: 14,7mm
Material thickness: 2,6mm. Engine Mounted A/C. 9.5 x 2.5mm. All Required. 9.5 x 2.6mm.
$7.99
$7.99
210
$3.45
270
Threaded Sleeve Mercedes-Benz
Mercedes-Benz Description: Hose line to suspension strut tower. Bracket mounting. Hydropneumatic spring leg dome. At floor. Clamp to underbody. Hose to firewall damping. To coolant line. Wiring harness. Line fastener to holder.
$18.20
$18.20
280
Clamp Mercedes-Benz
Mercedes-Benz Description: Refrigerant line to body. 10 mm + 16-19 mm black. Hydropneumatic spring leg dome. 10 mm + 16-19 mm black. Line to longitudinal member. 10 MM + 16-19 MM BLACK.
330
A/C Line O-Ring Mercedes-Benz
Mercedes-Benz Description: SUCTION LINE 13.7X2.5 MM. 13.7X2.5
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
Diameter: 18,7mm
Strength / hardness class: EPDM
Inside diameter: 13,7mm
Outside diameter: 18,7mm
Material thickness: 2,5mm.
$28.18
$28.18
340
Pressure Sensor Mercedes-Benz
Mercedes-Benz Description: Refrigerant line. Reservoir. Sprinter van. Refrigerant condenser. Refrigerant pressure sensor. Roof. Metris. Rear. At condenser,bottom m10.
$232.75
$232.75
361
$4.73
362
O-Ring Mercedes-Benz
Mercedes-Benz Description: Intake side. Upper. Expansion valve connection. Line to check valve. Piping to refrigerant compressor. Refrigerant line to connecting point and compressor 3/4". Evaporator. Refrigerant line to expansion valve .
$12.00
$12.00
362
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Piping to refrigerant compressor. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23,8mmOutside diameter: 28,6mmMaterial thickness: 2,4mm. Refrigerant line. 23.8X2.4Diameter: 28,6mmStrength / hardness class: EPDMInside diameter: 23, ...
$8.44
$8.44
364
O-Ring Mercedes-Benz
Mercedes-Benz Description: Separation point. 16.7x2.5. Engine Mounted A/C. 16.7 x 2.5mm. All Required. Roof Mounted A/C. 16.7 x 2.5mm. Refrigerant line to refrigerant line. 16.7x2.5. Suction line to compressor. 16.7x2.5. Refrigerant line connecting point. 16.7x2.5.
$32.50
$32.50
