Brake Lines for 2006 Mercedes-Benz CLS55 AMG
No.
Part # / Description / Price
Price
10
Suction Line
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Reservoir to hydraulic unit, with damper.
10
13
Suction Line Mercedes-Benz
Mercedes-Benz Notes: OBSERVE WIS
Description: To hydraulic unit, without damper.
$649.92
$649.92
16
Clamp Mercedes-Benz
Mercedes-Benz Notes: OBSERVE WIS
Description: Intake hose to pipeline. To hydraulic unit, without damper.
$8.50
$8.50
18
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Line attachment. Suction hose to hydraulics unit. Purge line to intake manifold.
$14.63
$14.63
20
Suction Line Mercedes-Benz
Mercedes-Benz Description: To hydraulic unit, with damper. Reservoir for hydraulic unit.
25
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Suction line to tank. 16/12 mm. Connector. 16/12 mm. Hose line mount. 16/12 MM. Intake line to intake pipe. 16/12 mm.
$6.65
$6.65
35
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Between combination valve and breather pipe. Regeneration valve. Return hose to return line. From fuel tank to breather valve.
$9.60
$9.60
50
Retaining Spring Mercedes-Benz
Mercedes-Benz Description: Brake hose mounting. Between master cylinder,front axle and bracket,frame. Rear axle. Front left. Brake hose to bracket. Line connections. Bracket, brake line/brake hose. Brake line to brake hose.
$5.25
$5.25
60
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From master cylinder to front right brake hose.
$95.70
$95.70
60
Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
TO BE ADAPTED DURING ASSEMBLY
TO BE ADAPTED DURING ASSEMBLY
Description: Master cylinder to hydraulic unit connection "hz1". Master cylinder connection "v" to hydraulic unit connection "v".
60
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: Master cylinder to hydraulic unit connection "hz1". Master cylinder connection "v" to hydraulic unit connection "v".
60
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From accumulator,connection "e",to adapter fitting. From hydraulic unit to left front wheel. Master cylinder connection "v" to hydraulic unit connection "v". From rear distributor to rear distributor to rear bracket. From hydraulic unit to adapter fitting, ...
$68.15
$68.15
64
Retaining Screw Mercedes-Benz
Mercedes-Benz Description: M12x1. Line connection. Brake line. Hydraulic line. Lines m 12x1. Dia., 6,3 . M 12. 620mm. From brake master cylinder to hydraulic unit.
$3.00
$3.00
70
Brake Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: Between hydraulic unit and coupling piece. 4.75 X 0.7 X 1750 MM. Vom ueberg.st.1 zum ueberg.st.2. 4.75 x 0.7 x 1750 mm. Master cylinder connection "h" to hydraulic unit connection "h". 4.75 x 0.7 x 1750 mm. From front master cylinder to asr hydraulic unit. 4.75 x 0.7 x 1750 mm.
$72.50
$72.50
70
Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
TO BE ADAPTED DURING ASSEMBLY
TO BE ADAPTED DURING ASSEMBLY
Description: Master cylinder to hydraulic unit connection "hz2". Master cylinder connection "h" to hydraulic unit connection "h".
70
Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
TO BE ADAPTED DURING ASSEMBLY
TO BE ADAPTED DURING ASSEMBLY
Description: Master cylinder to hydraulic unit connection "hz2". Master cylinder connection "h" to hydraulic unit connection "h".
80
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From hydraulic unit to left front wheel. From master cylinder to coupling. Hydraulic unit conn. "fr" to right front wheel. Red 1175 mm. From accumulator,connection "e",to adapter fitting. From hydraulic unit to adapter fitting,rear left. From accumulator,connection "e",to hydraulic unit,connection: "e". From distributor to coupling in the right of engine compartment.
$107.30
$107.30
80
Brake Line Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Repair line from hydraulic unit to left front wheel. 5000 MM. Repair line from hydraulic unit to front wheel at right. 5000 mm. Master cylinder to hydraulic unit connection "hz1". 5000 mm. Brake line towards front, left. 5000 MM. Master cylinder connection "v" to hydraulic unit connection "v". 5000 mm. Connecting point to connecting point. 5000 MM.
$245.00
$245.00
90
Retaining Screw Mercedes-Benz
Mercedes-Benz Description: M10x1. Left brake line. To line. Hydraulic line. M 10.
$14.25
$14.25
150
Holder Mercedes-Benz
Mercedes-Benz Description: Leak fuel line. Fuel pump on cross member. Fastening, right rear wheel brake line. Mount, brake line to rear floor. Engine hood release cable. Brake line in right-hand wheel house. Cable on tunnel. Fastening, right front wheel brakelineat firewall.
160
Holder Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: Brake line to transverse control arm, front left. Right front brake line to tunnel, bottom.
$7.23
$7.23
170
Line Fastener Mercedes-Benz
Mercedes-Benz Description: At bracket, left front. Fastening, hydraulic lines. On spring dome. Brake line to engine compartment partition panel,left. Brake line fastening.
$17.63
$17.63
180
Clamp Mercedes-Benz
Mercedes-Benz Description: Brake line to left front wheelhouse panel. Spacer for brake lines to partition. Brake line mount to hydraulic unit. Brake line to firewall. Brake line to fire wall, right. Major assembly partition wall. Standoff brake line over right frame side rail. Brake line fastening. Bunching and distancing brake line.
190
Clamp Mercedes-Benz
Mercedes-Benz Description: Heat duct to front longitudinal memb. Right 3,2mm. Brake line mounting to main floor right 3,2/4,7-6mm. Front right brake line mounting to right longitudinal member 3,2/4,7-6mm.
190
Line Bracket Mercedes-Benz
Mercedes-Benz Description: Major assembly partition wall. On partition panel,used for brake line right.
200
Holder Mercedes-Benz
Mercedes-Benz Description: Brake line mounting to wheelhouse right. Major assembly partition wall. Fastening, brake lines under hydraulicunit. Spacer brake lines between master cylinder & hydraulics unit. Spacing of brake lines.
$12.00
$12.00
220
Hose Section Mercedes-Benz
Mercedes-Benz Description: Brake line to fire wall. Right rear brake line to cross member. Chafe protection. Front right brake line mounting to right longitudinal member. 4,5 x 14,5 x 40. At brake line between hydraulic unit and frame bracket. To fuel line. To spring tower, left. Protection against scoring for pipe line.
$8.80
$8.80
240
Holder Mercedes-Benz
Mercedes-Benz Description: Fastening brake line to main floor left 4,7/8/8-10mm. Fastening fuel lines to longitudinal member.
$11.20
$11.20
250
Line Bracket Mercedes-Benz
Mercedes-Benz Description: Brake line to partition panel. For brake lines of rear wheels. Brake line fastening to maj. Assembly comp. Partition wall. On suspension strut console,left.
$15.00
$15.00
250
Clamp Mercedes-Benz
Mercedes-Benz Description: Fuel line mounting. At partition panel,right. To mount fuel lines. On partition panel,used for brake line right. Brake line mounting to main floor right. Brake line fastening.
260
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From connector do distributor. From adapter fitting to distributor.
$100.05
$100.05
280
Line Bracket Mercedes-Benz
Mercedes-Benz Description: Hydraulic unit to partition wall. Line mount. Hydraulic line on partition. Scuff protec. For brake line.
280
Damping Strip Mercedes-Benz
Mercedes-Benz Description: To mount fuel lines. Extinguishing agent line. To rear floor left. Fuel/brake/breather lines to main floor. Scuff protec. For brake line.
320
Line Mercedes-Benz
Mercedes-Benz Description: From adapter fitting to brake pressure regulator. 4.75 x 0.7 x 3865 mm. From front master cylinder to distributor. 4.75 x 0.7 x 3865 mm. From right coupling piece to rear self-levelling unit. 4.75 x 0.7 x 3865 mm. From brake master cylinder to distributor. 4.75 x 0.7 x 3865 mm.
$165.30
$165.30
330
Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: Between coupling piece and bracket, frame. 4.75x0.7x2740 mm. From master cylinder,connection "v",to hydraulic unit,connection: "v". 4.75x0.7x2740 mm.
$137.75
$137.75
340
Brake Line Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: From hydraulic unit to right front wheel 2000 mm. 4.75x0.7x2000 mm. Between hydraulic unit and coupling piece. 4.75X0.7X2000 MM. Between master cylinder for rear axle and bracket for frame. 4.75x0.7x2000 mm. From adapter fitting to brake hose, rear left. 4.75x0.7x2000 mm. Blue 2000 mm. 4.75x0.7x2000 mm. From rear master cylinder to hydraulic unit,connection: "v". 4.75x0.7x2000 mm. From brake power regulator to right front wheel. 4.75x0.7x2000 mm.
$129.05
$129.05
370
Hexagon Spacer Element Mercedes-Benz
Mercedes-Benz Description: Connection. M10. Between hydraulic unit lines and left/right rear axle lines. Brake line. Coupling piece to left rear wheel. Vom ueberg.st.2 zum vorderrad links. Adapter. Between the lines.
$16.13
$16.13
