Cable Harnesses for Special Vehs for 2002 Mercedes-Benz E430
No.
Part # / Description / Price
Price
150
El Cable
Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Roof extension info emergency vehicle. Special signal system.
155
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Plug socket 12v. Pass. Left rear reading lamp. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Additional heater control unit. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Radio connection x58/2. 2-pin ff6.3model 1: ffmodel 2: 6.3slots: 2. Front interior socket ...
$11.63
$11.63
160
Male Spade Connector Mercedes-Benz
Mercedes-Benz Description: Silver-plated. 2.5-4.0 MM2 PL6.3
Leitungsquerschnitt Min/Max: 2,5-4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: PL
Model 2: 6.3. RADIO CONNECTION X58/2. 2.5-4.0 MM2 PL6.3
Leitungsquerschnitt Min/Max: 2,5-4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: PL
Model 2: 6.3.
Leitungsquerschnitt Min/Max: 2,5-4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: PL
Model 2: 6.3. RADIO CONNECTION X58/2. 2.5-4.0 MM2 PL6.3
Leitungsquerschnitt Min/Max: 2,5-4,0mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: PL
Model 2: 6.3.
170
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
$15.75
$15.75
175
Coupling, Mechanical Mercedes-Benz
Mercedes-Benz Description: Burglary alarm system control unit. 33-pin jpt. Multi-function control module for spec. Purp. Veh. N26/14. 33-pin jpt.
175
Cap Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Panic alarm system control unit connector n26/8*2. 33-pin jpt. Panic alarm system control unit connector n26/8*1. 33-pin jpt. To 016 545 87 28. 33-pin jpt. Multifunction control module, 33-pin. 33-pin jpt. Control unit danger warning system n26/8. 33-pin jpt. To 016 545 57 28. 33-pin jpt.
180
Contact Spring Mercedes-Benz
Mercedes-Benz Description: Left exit lights. 0.5 mm2 jpt. To 220 545 17 28. 0.5 mm2 jpt. 0,5-1,0mm2. 0.5 mm2 jpt. Radio 0.5 -1.0 mm2. 0.5 mm2 jpt.
$8.40
$8.40
180
Spring Retaining Pin Mercedes-Benz
Mercedes-Benz Description: 1.5-2.5mm2. 1.5-2.5 MM2 JPT2.8
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
Leitungsquerschnitt Min/Max: 1,25-2,5mm2
Oberflächenschutz PINs: Ag
ELA: -
Model 1: JPT
Model 2: 2.8
Release tool: W000 589 13 99 30
Crimp tool: W220 589 01 99 05.
$9.20
$9.20
185
Housing Upper Part Mercedes-Benz
Mercedes-Benz Description: To 009 545 78 28. To 009 545 80 28. Pin bushing housing 6-polig. To 006 545 08 28. To 006 545 78 28 (asr). 6-pole. To 006 545 80 28,123 545 06 28. (plug upper part).
$8.08
$8.08
200
Receptacle Housing Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: Transmission shifting lock. 2-pin. Parking interlock. 2-pin. Back-up lock and cruise control. 2-pin. Plug connection,entrance illumination,doors front left and right 2-polig. 2-pin.
$29.25
$29.25
210
Contact Socket Mercedes-Benz
Mercedes-Benz Description: 4 MM. 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Max: 0,35-2,5mm2Oberflächenschutz PINs: AgELA: -Model 1: RKModel 2: 2.5Release tool: W220 589 01 99 30 / W220 589 01 99 53Crimp tool: W220 589 01 99 06. 2,5 (AX). 0.35-2.5 MM2 RK2.5Leitungsquerschnitt Min/Ma ...
$7.23
$7.23
215
Cable Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: FUSE BOX. 4.0 MM2 GSK1
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
Leitungsquerschnitt Min/Max: 4,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
215
Electric Line Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: FUSE BOX 0.35--1.0 MM2. 1.0 MM2 GSK1
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
Leitungsquerschnitt Min/Max: 1,0mm2
Oberflächenschutz PINs: -
Model 1: GSK
Model 2: 1.
$6.80
$6.80
320
Receptacle Housing Mercedes-Benz
Mercedes-Benz Description: Left ventilator window. 6-pin. Roller blind switch. 6-pin. Switch esp-off. 6-pin. Switch, rear window blind. 6-pin. Switch "asr". 6-pin.
330
Electrical Wiring Harness Mercedes-Benz
Mercedes-Benz Notes: CONNECTORS MUST ALSO BE ORDERED IN ACC. WITH THE TOTAL CABLE C ROSS-SECTION TO BE CONNECTED.
SEE WIS FOR REPAIR INSTRUCTIONS.
=================================================================================================
SOLDER CONNECTOR SLEEVES: TOTAL WIRE CROSS-SECTION:
A 001 546 99 41 GREEN 0.7 - 2.4 MM2
A 002 546 00 41 RED 2.0 - 4.0 MM2
A 002 546 01 41 BLUE 3.5 - 8.0 MM2
A 002 546 11 41 YELLOW 7.5 - 12.0 MM2
BUTT JOINT:
A 002 546 13 41 0.5 MM2
A 002 546 14 41 0.8 MM2
A 002 546 15 41 1.3 MM2
A 002 546 16 41 2.0 MM2
===================================================================================================
Description: Repair solution contacting 0.75mm2. 0.75 mm2 e95. Fuse box. 0.75 mm2 e95.
$14.25
$14.25
