Closed Fuel-Evaporation-Control System for 2002 Mercedes-Benz CL55 AMG
No.
Part # / Description / Price
Price
20
Hose
Mercedes-Benz
Mercedes-Benz Description: Fluid reservoir. Purge valve to connecting point. Activated charcoal filter to purge valve. Regeneration valve to throttle housing. To purge line. At intake manifold. Molded hose. From regeneration line to engine. Intake manifold to purge valve,left. From right regeneration valve to engine.
30
Purge Valve Mercedes-Benz
Mercedes-Benz Description: Regeneration valve. Evaporative emission control system. In engine compartment.
60
Hose Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
TO BE ADAPTED DURING ASSEMBLY
TO BE ADAPTED DURING ASSEMBLY
Description: 160 mm. 13.3x3 mm. From fuel filter to feed line. 13.3x3 mm. 300 mm. 13.3x3 mm. 110mm. 13.3x3 mm. Order by the meter. 13.3x3 mm. 250 mm. 13.3x3 mm. From activated charcoal filter to regeneration valve. 13.3x3 mm. 100 mm from fuel return line to fuel tark. 13.3x3 mm.
$56.55
$56.55
80
Hose Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
NO LONGER AVAILABLE
TO BE ADAPTED DURING ASSEMBLY
NO LONGER AVAILABLE
TO BE ADAPTED DURING ASSEMBLY
Description: On fuel filter. 11,5X3MM. Return. 11,5x3mm. Activated charcoal filter on purge line 125mm. 11,5x3mm. Activated charcoal filter on purge line 125 mm. 11,5x3mm. 110mm. 11,5x3mm.
100
Hose Mercedes-Benz
Mercedes-Benz Notes: TO BE ADAPTED DURING ASSEMBLY
Description: Breather line to activated charcoal filter 132mm. Breather line to activated charcoal filter 13,3x3mm.
140
Valve Mercedes-Benz
Mercedes-Benz Description: To vent pipe tank. To tank breather pipe. Feed and return lines, breathing. Vent line. Vent valve.
$44.95
$44.95
150
Hose Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
TO BE ADAPTED DURING ASSEMBLY
TO BE ADAPTED DURING ASSEMBLY
Description: Activated charcoal filter for purge line. 15,3X3MM. Hose to valve 55mm. 15,3x3mm. Feed and return lines, breathing 55mm. 15,3x3mm. Return line to fuel filter 200mm. 15,3x3mm. Vent pipe fuel tank to t-fitting or vent valve 50mm. 15,3x3mm. Vent line 45 mm. 15,3x3mm. Purge line to check valve. 15,3x3mm. From activated charcoal filter to regeneration line. 15,3x3mm.
$42.05
$42.05
160
Spring Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Hose to fuel tank. Suction hose to induction line. Feed and return lines, breathing. From fuel tank to breather valve. (vent line) from activated charcoal filter to boot. Vent pipe fuel tank to t-fitting or vent valve. Vent hose to activated charcoal filter.
$7.65
$7.65
170
Grommet Mercedes-Benz
Mercedes-Benz Description: To tank drainage. Vacuum line. On rear end floor. At side member, exterior left 26 mm.
No.
Part # / Description / Price
Price
65
Hose Clamp Mercedes-Benz
Mercedes-Benz Description: Cexpansion reservoir to activated charcoal filter. 13mm.
$15.75
$15.75
150
Hose Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
TO BE ADAPTED DURING ASSEMBLY
TO BE ADAPTED DURING ASSEMBLY
Description: 65 mm.
$145.00
$145.00
310
Hose Mercedes-Benz
Mercedes-Benz Notes: ORDER BY THE METER
Description: Breather line to activated charcoal filter. From fuel-oil pump to heater.
320
Hose Clamp Mercedes-Benz
Mercedes-Benz Description: FUEL TANK TO HOSE. 9 MM - 9.5 MMInside diameter: 9,5mmOutside diameter: 11mmMaterial thickness: 0,6mm. BREATHER LINE TO ACTIVATED CHARCOAL FILTER. 9 MM - 9.5 MMInside diameter: 9,5mmOutside diameter: 11mmMaterial thickness: 0,6mm. FUEL PUMP TO TANK. 9 MM - ...
$7.13
$7.13
340
Valve Mercedes-Benz
Mercedes-Benz Description: Shutoff valve. Shut-off valve. Evaporative emission control system. Activated charcoal filter.
$240.10
$240.10
340
Valve Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: On activated charcoal filter. Shutoff valve.
345
Sealing Ring Mercedes-Benz
Mercedes-Benz Description: Activated charcoal filter. Shutoff valve activated-carbon filter. At valve.
350
Hose Mercedes-Benz
Mercedes-Benz Notes: NO LONGER AVAILABLE
Description: From t-fitting to tank connection. Activated carbon filter to tank conn. Breather line to activated charcoal filter.
380
Binder Mercedes-Benz
Mercedes-Benz Description: Hose fastening. 26.5 mm. Between activated charcoal filter and regeneration valve. 26.5 mm. Hose to filler neck. 26.5 mm. (vent line) from activated charcoal filter to boot. 26.5 mm. From tank to vent line. 26.5 mm. Activated charcoal filter to shut-off valve. 26.5 mm. Hose to purge valve. 26.5 mm.
$10.00
$10.00
510
Sealing Grommet Mercedes-Benz
Mercedes-Benz Description: Breather line thru floor. Line through vehicle floor. Wheel arch.
710
Rubber Bushing Mercedes-Benz
Mercedes-Benz Description: Brake line to rear seat floor right. Ant-chafe protection to longitudinal member. Line to side member. Line aux.heater right rear seat floor.
